MS-836
11,6mm - 22,6mm Mid Span Slit & Ring Tool for RocketRibbon® Cable
Catalogue index: MS-836
- Availability: On demand
- Delivery time: Completion from 1 to 6 weeks
- Delivery: from PLN18.00 (DPD Courier (1-2days))
- Self pickup: free
- Cable Diameter [mm]:
- Condition:
- EAN code:
- 810053352229
- Mark:
- Country of origin:
- Catalogue index:
- MS-836
Description
The patented MS-836 Mid Span Slit & Ring Tool is designed to provide easy access to optical ribbon fibers in Corning's RocketRibbon® cable. Building on the popularity of the Jonard Tools MS-6 and MS-26 Fiber Optic Mid Span Slitting Tools, we have incorporated a ring feature in the tool to make it even more versatile.
- one side of the tool performs radial/ring cuts and the other side slits the cable (longitudinal cut)
- indicator line on top of the unit indicates the position of the blade for accurate slitting and ringing
- blades last for 5,000 slits or rings
Specifications:
- groove sizes: 11,6mm - 12,0mm; 14,5mm - 14,9mm; 16,8mm - 17,2mm; 22,2mm - 22,6mm
- cut type: slit, ring
- number of slitting grooves: 4
- number of ringing grooves: 4
- cable type: Corning RocketRibbon®
- cable diameter: 11,6mm - 22,6mm
- weight: 0lb (0g)
- UPC #: 810053352229
- replacement blade #: MS-836RB
