OFI-100 Advanced Optical Fiber Identifier with Power Meter & VFL

Designed to quickly identify the direction of light being  transmitted in the fiber and display the relative core power without damaging the fiber. This fiber identifier is the perfect tool for identifying fiber in network systems without disrupting the network and includes a built-in VFL and Power Meter for convenience. This fiber identifier also features the following:
- reversible adapter has one side for 2mm and 3mm fiber optic cables, and the opposite side is used for 250µm and 900µm fiber
- built-in VFL allows you to find faults in fiber cables quickly and easily
- built-in Power Meter can be used to measure power using 850, 1300, 1310, 1490, 1550, and 1625nm wavelengths

Specifications:
- identified wavelength range: 800-1700nm
- identified signal type: CW, 270Hz±5%，1kHz±5%，2kHz±5%
- detector type: Ø1mm InGaAs
- adapter type: Ø0,25 (applicable for bare fiber), Ø0,9, Ø2,0 i Ø3,0
- signal direction: color display
- signal direction test range: -46 ~ +10dBm (1310nm, CW/0,9mm bare fiber), -50 ~ +10dBm (1550nm, CW/0,9mm bare fiber)
- signal frequency display: 270Hz, 1kHz, 2kHz
- insertion loss: 1,0dB (Ø0,25 & Ø0,9), 1,5dB (Ø2,0 & Ø3,0)
- battery type: 2 AA
- dimensions: 9" x 1,73" x 2,1" (22,86cm x 4,38cm x 5,33cm)
- weight: 0,59lb (267,86g)
- UPC #: 810053351529

Included items:
- Advanced Fiber Identifier
- Adapter for 2,0/3,0mm & 250/900nm fibers
- 2 AA Batteries
- Carrying pouch
